Trail Edition Rock Sliders for 2005-2023 (2nd & 3rd Gen) Toyota Tacoma

Trail Edition rock sliders (also called rock rails) for the 2005-2023 (2nd and 3rd Gen) Toyota Tacoma. They bolt to the frame, angle up 25 degrees for more clearance on rocks and ledges, and protect your rocker panels. Fits Access Cab and Double Cab short bed and long bed trucks, installs in about 1 to 2 hours with no drilling, and ships free from our shop in Fort Worth, Texas. Want a flat step instead? See the Step Edition for the same truck.

Read the full overview and specs
ON SALE

From $909.49 $1,069.99

See payment options
Product Options
Kick Out No Kick Out
Raw Steel Powder Coat Bedliner
Double Cab Short Bed Double Cab Long Bed Access Cab
Fits:Toyota Tacoma 2005-2015, Toyota Tacoma 2016-2023
Secure checkout · Shop Pay & all major cards
Trail Edition Rock Sliders for 2005-2023 (2nd & 3rd Gen) Toyota Tacoma $909.49

Before you buy

Popular setup
Kick out, powder coat slider.
Options explained
Kick out or no kick out?
Kick out vs no kick out rock sliders side by side. Kick out has an angled rear end, no kick out is straight.

Kick out angles the back of the slider out, in front of the rear tire, so the back of your truck doesn't get pinned on rocks. No kick out runs straight for a clean look. Same price either way.

Full kick out guide

Which finish should I pick?
Rock slider finishes: raw steel for custom color, black powder coat recommended for the slider, bed liner recommended for the top plate.

Raw steel: bare steel that will rust if left uncoated. Paint or coat it right away. Powder coat: black, ready to bolt on. Bedliner: rugged textured finish with extra grip.

Full coatings guide

Fitment
  • Fits 2005–2023 Tacoma Access Cab, Double Cab Short Bed and Double Cab Long Bed. Select your cab and bed.
  • Top plates are not included or offered on Trail Edition.
  • Does not fit 2024+ Tacoma.

Trail Edition Sliders for the 2nd and 3rd Gen Tacoma

Each slider mounts to a full 3/16-inch steel frame plate with front and rear clamps that hook over the frame, so a hit on the rocks goes into the frame instead of the body. The tubing is fully gusseted, and with no top plates the Trail Edition stays tucked tight to the body and out of the way on technical trails.

Every set is designed and fabricated in-house and covered by a 2-year warranty, powder coat included.

Specs

2005-2023 Tacoma Trail Edition rock sliders: specs
Fits2005-2023 Toyota Tacoma (2nd and 3rd Gen), Access Cab and Double Cab short or long bed
Tubing1.75-inch DOM, .120-inch wall
MountingFull 3/16-inch frame plate, front and rear clamps
LoadHolds the full weight of the vehicle; works as a jack point
Length81 inches (Access Cab and short bed), 94 inches (long bed)
WeightAbout 100 lb per set
FinishRaw, black powder coat or bedliner
InstallBolt-on, no drilling, 1 to 2 hours
In the box2 sliders, Grade 8 hardware
ShippingFree LTL freight
Warranty2 years, powder coat included

Trail Edition or Step Edition?

Trail Edition vs Step Edition: 2005-2023 Tacoma
Trail Edition (this page)Step Edition
Angle25 degrees up, tucked to the body0 degrees, flat step
Top platesNoneOptional top plates to stand on
Weight per setAbout 100 lbAbout 120 lb
Best forTrail clearance, technical terrainDaily driving, passengers, roof access

Questions

Will these rock sliders fit my 2005-2023 Tacoma?

Yes. They fit 2005-2023 (2nd and 3rd Gen) Tacomas in Access Cab, Double Cab short bed and Double Cab long bed, including Base, SR, SR5, TRD Sport, TRD Off-Road, Limited and TRD Pro. Select your cab and bed when you order. They do not fit the 2024+ Tacoma.

What tubing are these Tacoma sliders made from?

1.75-inch DOM tubing with a .120-inch seamless wall, on a full 3/16-inch carbon steel frame plate. DOM tubing is drawn over a mandrel after welding, so its size and wall are more uniform than plain welded (HREW) tubing.

Can these sliders hold the weight of my Tacoma, and can I jack from them?

Yes. Each slider bolts to the frame through a full 3/16-inch steel frame plate with front and rear clamps that hook over the frame, so it can hold the weight of your Tacoma and works as a jack point.

Should I get the Trail Edition or the Step Edition for my Tacoma?

Get the Trail Edition if you want more clearance: it angles up 25 degrees, stays tucked to the body, has no top plates and weighs about 100 lb per set. Get the Step Edition if you want a flat 0-degree step for daily driving, passengers and roof access. It offers optional top plates and weighs about 120 lb per set.

Are these rock sliders bolt-on, and how long does install take on a Tacoma?

Yes. They bolt on with no drilling, and install takes about 1 to 2 hours. At about 100 lb per set, plan on a helper or a floor jack to hold each slider. The only trim is a small notch in the passenger-side plastic wiring cover so it fits over the slider gusset.

Will these fit both my 2nd Gen and 3rd Gen Tacoma?

Yes. The same sliders fit 2005-2023 Tacomas and install the same way. On 2016 and newer trucks (and select models) you unbolt and hang the frame black box during install, and 2nd Gen two wheel drive trucks use four frame bolt positions instead of three.

How far do these sliders stick out from my Tacoma?

Measured from the pinch weld (the seam under the doors), the Trail Edition sits about 6 5/8 inches out with kick out and about 3 3/4 inches out with no kick out, give or take 1/2 inch. The 25-degree angle keeps it about 3 inches tighter to the body than the Step Edition. Kick out sits farther out because the rear of the slider angles out in front of the rear tire.

More questions? Call 888-385-5036 or email support@caliraisedled.com.

Installation

Read installation steps

How to Install 2005-2023 Toyota Tacoma Rock Sliders

Watch the video, then follow the written steps below to bolt Cali Raised LED Rock Sliders onto your 2005-2023 Toyota Tacoma (2nd and 3rd Gen) Access Cab or Double Cab, short or long bed. The Step Edition (0 degree flat step) and the Trail Edition (25 degree angle) install the same way. The video shows a 2019 Tacoma; where 2nd Gen trucks or trucks without the frame black box differ, the step says so.

Installation steps

Before you start: You need a helper to lift each slider (Trail Edition is about 100 lb per set, Step Edition about 120 lb per set). Tools: 10, 12 and 14 mm wrenches, 9/16 and 3/4 in. wrenches, a 10 mm deep socket, 9/16 and 3/4 in. sockets with a ratchet, a flat screwdriver or pry bar, and a knife or snips. A magnetic flashlight helps. Install time is 1 to 2 hours. Bolt-on, no drilling. Leave every bolt hand tight until the tightening sequence. Raw steel sliders must be coated right away to prevent rust.

  • Step 1: Driver side prep (12 mm, flat screwdriver). Remove the two black box nuts and let the box hang (2016 and newer, and select models). Loosen the wiring harness bracket bolt, release the brake line clips and harness clamps, and remove the rectangle and round frame caps (stickers on some trucks). Remove the brake line bracket bolt, pull the lines lightly away, then remove the bolt behind them and twist out the inside plastic cover.
  • Step 2: Set the backing plate. Clip the square nut into the rectangular backing plate, then slide the plate into the rectangular hole in the frame crossmember with the nut on top. This must be in place before the slider goes up.
  • Step 3: Remove the bottom bolt (14 mm). Remove the 14 mm bolt at the bottom of the frame and keep it.
  • Step 4: Passenger side prep (10 mm, 12 mm, 14 mm). Remove the plastic wiring cover (two 10 mm bolts) and the two 12 mm bracket bolts, and let the bracket dangle. Remove the frame caps, set the backing plate nut up, and remove the 14 mm bottom bolt.
  • Step 5: Hang the driver slider (14 mm). With a helper, lift the slider to the frame, line up the only oval hole on the frame plate, and thread the 14 mm bolt in at least three turns. Do not tighten it yet.
  • Step 6: Install the 1/2 in. frame bolts. Each is bolt, washer, slider, rectangle backing plate, washer, nut. The 2019 in the video has three positions; 2nd Gen two wheel drive trucks have four. On the driver side forward position only, the bolt goes in from the inside so the black box clears.
  • Step 7: Install the clamps. Each is bolt, washer, frame plate, spacer, clamp (hook down), washer, nut. Front and center get 2-1/2 in. bolts with short spacers; the rear gets the 3 in. bolt with the long spacer. The clamp hooks over the inside lip of the frame.
  • Step 8: Install the front handle. Clip the square nuts into the handle (not the long side), top of the nut on the side where the handle bends out. Slide the handle inside the frame over the brake lines and start two 1/2 in. bolts through the front frame plate, about two turns each. Then reach through the long slotted hole, move the square nut into place and install that bolt.
  • Step 9: Reinstall the driver parts (14 mm, 12 mm). Tighten the 14 mm bolt to snug the frame plate, then the reversed forward bolt. Clip the brake lines into their factory holes and reinstall the black box. No black box? Use the 3/8 in. hardware in those two holes.
  • Step 10: Level and tighten. Line the slider's straight edge up with the cab by lifting the front or pushing down the back. Tighten from the front: 1/2 in. frame bolts, front frame plate bolts, bottom bolts, then clamps. Reinstall the harness bracket, black box nuts and brake line clamp bolt.
  • Step 11: Install the passenger side (same tools). Repeat Steps 5 to 8 with every bolt in from the outside. If the wiring bracket doesn't use all its holes, slide a spare backing plate behind it as a spacer. Optional 3/8 in. bolts go in the two small holes, not the larger third hole. Level and tighten as in Step 10, then the two 12 mm bracket bolts and the 3/8 in. bolts.
  • Step 12: Notch and reinstall the passenger plastic cover (knife or snips, 10 mm). The slider gusset sits behind the plastic wiring cover. Cut a small notch next to its mounting bolt, then reinstall the cover in its factory spot with the notch over the slider.

Final check: Confirm the slider is level with the cab, every bolt is tight, the brake lines are clipped in, the black box and wiring bracket are back on, and the passenger plastic cover is in place. Coat raw steel sliders right away. Questions? support@caliraisedled.com or 888-385-5036.
